Color Sorter

COLOR SORTER also named color sorting machine, color sorter machine or optical sorting machine, it is according to the color differences of granular materials, using high-resolution CCD optical sensor to drive solenoid valve to sorting different granular materials.CSG Color Sorter has been widely used in many industry in the world. Such as agricultural products, food and mining industries, The most common use is sorting rice, wheat, corn, peanut, a variety of beans, seeds, tea, herbs, dried vegetables, recycled plastic, salt and ore etc.


Rice Color Sorter Machine Type

Chute Type Color Sorter Machine

64 Channels Sorting Machine

1 chute 64 channels color sorter


128 Channels Sorting Machine

2 chutes 128 channels color sorter


192 Channels Sorting Machine

3 chutes 192 channels color sorter


256 Channels Sorting Machine

4 chutes 256 channels color sorter


320 Channels Sorting Machine

5 chutes 320 channels color sorter


384 Channels Sorting Machine

6 chutes 384 channels color sorter


Chute Color Sorter

Apply to sorting: Rice, Wheat, Corn, Maize, Millet, Sorghum, Quinoa, Buckwheat, Oats, Barley, Cardamon, Sesame Seeds, Groundnut, Peanut, Soybean, Coffee Bean, Pea, Mung Bean, Lentil, Vicia Faba, Fava Bean etc.


Multilayer Color Sorter

Apply to sorting: Tea, Dehydrated Vegetables, Herb, Dried Flower, Leaf Products etc


Belt-type Color Sorter

Apply to sorting: Nuts, Cashew, Almond, Pistachio, Sunflower Seeds, Watermelon Seed, Raisin, Lycium Chinense, Jujube, Cotton Seed, Chili, Shrimp Skin, Ore, Coal, Salt, Sugar, Glass, Plastc, Pearl, Pill, Gum, Industrial products etc.


Installation & Maintenance Guide

Rice Color Sorter Advantage

Control board chip is made in the USA, The combination of DSP and FPGA produces powerful computing capabilities. It has fast data collection and can process large amounts of information with large capacity dealing. Distinguished performance to kinds of colorful products graininess.
300mm wide chute which is smoothness,abrasion-resistance, resistance to wear and tear and corrosion-resistance is built with a special anodizing process and was designed to meet specifications required for different size material.

5400 pixel camera chip original imported from Japan Toshiba ensured the excellent color selection. The maximum resolution is up to 0.035mm, can accurately identify small defects and spots on Raw materials, and the high-precision special lens ensures clear images.
High-frequency electromagnetic solenoid valve from Japan SMC or China block valve can operate with 8-14 times millisecond, precision and consistency of the near-zero error to ensure high accuracy. Air filter and rodless cylinder from Festo customerized also.
FlexibleLed lighting system can be adjusted to any background color to meet different material sorting task with one machine.




10-inch large screen with an Image processing system, wifi and remote-control function added make machine operation and maintenance easier (Optional).




Color Sorter Parameter

5340 pixel Multi Colorful CCD Color Sorter
Machine information
Model.NO. R1 R2 R3 R4 R5 R6 R7 R8 R10 R12
weight(kg) 210 350 600 780 880 1000 1150 1250 1400 1650
channels 64 128 192 256 320 384 448 512 640 768
ejectors Jpan SMC Jpan SMC Jpan SMC Jpan SMC Jpan SMC Jpan SMC Jpan SMC Jpan SMC Jpan SMC Jpan SMC
light source FlexibleLED FlexibleLED FlexibleLED FlexibleLED FlexibleLED FlexibleLED FlexibleLED FlexibleLED FlexibleLED FlexibleLED
pixel of camara 5340 5340 5340 5340 5340 5340 5340 5340 5340 5340
Capacity  (T/H) 0.5-3.0 1.0-4.0 2.0-6.0 3.0-8.0 5.0-10.0 6.0-12.0 9.0-17.0 11.0-20.0 12.0-22.0 13.0-25.0
Sorting accuracy 99.50% 99.50% 99.50% 99.50% 99.50% 99.50% 99.50% 99.50% 99.50% 99.50%
Sorting ratio 15:01 15:01 15:01 15:01 15:01 15:01 15:01 15:01 15:01 15:01
Power(KW) 1 1.4 1.8 2.2 2.6 3.2 3.5 4 5 6
Air pressure ≥0.6Mpa ≥0.6Mpa ≥0.6Mpa ≥0.6Mpa ≥0.6Mpa ≥0.6Mpa ≥0.6Mpa ≥0.6Mpa ≥0.6Mpa ≥0.6Mpa
Air consumption (L/Min) 400-800 600-1000 800-1600 1000-1800 1300-2200 1500-2800 1800-3600 2200-4000 2400-4500 2700-5000
Power supply (Voltage/HZ) 110-250V 50-60HZ  110-250V 50-60HZ  110-250V 50-60HZ  110-250V 50-60HZ  110-250V 50-60HZ  110-250V  50-60HZ  110-250V  50-60HZ  110-250V 50-60HZ  110-250V 50-60HZ  110-250V 50-60HZ
Package wooden box wooden box wooden box wooden box wooden box wooden box wooden box wooden box wooden box wooden box

Sunrise Ccd Color Sorter Features

Color Touch Screen

The color touch screen eliminates the need to correct the touch position, window-type human-machine dialogue, simple operation, and flexibility.

High Brightness, Long Life

The color sorting machine adopts a high-brightness, long-life LED light source, which not only ensures high-definition images, but also satisfies a variety of color sorting, positive selection, reverse selection, and re-selection.

High Frequency Solenoid Valve

The color touch screen eliminates the need to correct the touch position, window-type human-machine dialogue, simple operation, and flexibility.

High Resolution Color CCD

The color sorter adopts high-resolution color ccd (5000*3 pixel technology) and adopts domestic first-class optical lens to effectively recognize smile impurities as small as 0.1 square millimeter.


Excellent After-sales Service

The value of work comes from good service to each other. We should not only let the consumers using sunrise products feel the quality service, but also let our internal customers enjoy the quality service.


Rich Experience

Sunrise was established in 2016. It is a comprehensive high-tech enterprise integrating scientific research, development, production, sales and service of CCD intelligent color sorter and near-infrared color sorter.

Rice Color Sorter Sorting Samples

1.The color performance above takes the japonica rice with impurity content of 2% as an example. Specific indexes may vary with the difference in materials and impurities.
2.There will not be further notice about product updating, and users should refer to the actual conditions of the machine.


Color Sorter Solutions

World leading sorting solutions for different products

Rice Sorting

rice optical sorting machine

Bean Sorting

bean optical sorting machine

Corn Sorting

corn optical sorting machine

Wheat Sorting

wheat optical sorting machine

Peanut Sorting

peanut optical sorting machine

Nuts Sorting

nuts optical sorting machine

Tea Sorting

tea optical sorting machine

Seeds Sorting

seeds optical sorting machine

Vegetables Sorting

rice optical sorting machine

Salt Sorting

salt optical sorting machine

Ore Sorting

ore optical sorting machine

Plastic Sorting

plastic optical sorting machine

Color Sorter Working Principle

Sunrise Color Sorting Machine's working principle is according to the difference of the optical properties of the material, use photoelectric detection technology and Full-color high-definition CCD camera image acquisition system, get (RGB) red, green, and blue color information, depth identification of small and fine impurities, send signal to ejector, and use compressed air drive ejector to automatic sorting the heterochromatic granule from raw material.

Sunrise Color Sorter use world top SENSOR-BASED OPTICAL SORTING TECHNOLOGY, sorting range from 0.01mm to 5 cm, sorting precision more than 99.9%. Solve the high dust, high output, complex colors, etc sorting problems under harsh environment.
